The Domino XM2 Quick-Action Twist Throttle Grip is a twin-cable push/pull throttle control designed for racing and performance motorcycle applications. It uses three interchangeable pulley rings to alter throttle response for faster, progressive sport or softer wet-condition operation, allowing the control characteristics to be matched to the riding conditions. The unit is supplied with rubber grips and requires dedicated XM2 universal or model-specific throttle cables, as standard throttle cables should not be assumed to be compatible.

Features

Twin-cable push/pull throttle operation
Three interchangeable pulley rings provide selectable throttle response
White pulley provides faster throttle operation for normal use
Red pulley provides a more progressive response for sport riding
Developed in collaboration with Moto2 racing teams
Intended for racing, performance applications and increased power demands
Supplied with rubber grips
Uses standard mounting locations where compatible
Designed with an OEM-style fit and appearance
Suitable as a replacement throttle control where compatible
Designed for straightforward installation

Specifications

Throttle support material: aluminium alloy
Support finish: painted
Colour: black
Screws and nuts: titanium
White ring opening: 55°
Red ring opening: 53°
White pulley quickness: 2.6°/mm
White pulley maximum stroke: 36 mm
Red pulley quickness: 2.7°/mm
Red pulley maximum stroke: 25 mm
Cable configuration: twin-cable push/pull
Throttle cables: not included

Cross-Reference OEM Part Numbers

5176.03-02
97.5176.04-00
5430.96.04-00
5405.96.04-00
5408.96.04-00
5424.96.04-00
5434.96.04-00
5427.96.04-00

Vehicle Fitments

Honda CBR600RR – 2007–2016 – requires XM2 throttle cables 5405.96.04-00
Honda CBR1000RR – 2008–2016 – requires XM2 throttle cables 5408.96.04-00
Yamaha YZF-R1 1000 – 2009–2014 – requires XM2 throttle cables 5424.96.04-00
Yamaha YZF-R1 1000 – 2015–2019 – requires XM2 throttle cables 5434.96.04-00
Yamaha YZF-R6 600 – 2008–2016 – requires XM2 throttle cables 5427.96.04-00
Other motorcycles using a twin-cable push/pull throttle system may be compatible when fitted with the appropriate XM2 universal cables 5430.96.04-00 or dedicated model-specific cables

Installation Notes

Dedicated XM2 universal or model-specific throttle cables are required
Standard throttle cables should not be assumed to fit
Check the product image, throttle arrangement and cable requirements before ordering to confirm suitability
Installation by a qualified motorcycle workshop is recommended if the correct fitting procedure is uncertain
