PISTON KIT 2013 EC300F 83.00 A, WOSSNER 8875DA

Wossner forged piston kit 8875DA is a standard-size piston with an 83mm bore (measured at 82.94mm) designed for the GASGAS EC300F 4-stroke model from 2013 onward. Engineered for strength, precision, and optimal thermal transfer, this German-made piston kit is ideal for reliable engine performance and durability.

Features

• Forged piston construction for maximum strength and durability

• Elliptical design for consistent bearing surface under heat expansion

• Efficient combustion heat transfer to cylinder walls

• Prevents piston collapse through even thrust load distribution

• Made in Germany

Specifications

• Bore: 83mm (Measured: 82.94mm)

• Display Volume: 290 cm³

• Stroke: 53.60mm

• Clearance: 0.06mm

• Compression Height: 22.20mm

• Wossner Compression Ratio: OEM

• OEM Compression Ratio: 13.50:1

• Dome Volume: -6.30 cm³

• Part No.: 56-W912.A.WO (Wossner 8875DA)

• Ring Set: 830XDS

• Lock P/N: CW16

• Pin P/N: WP059

Vehicle Fitments

• 2013–onward GASGAS EC300F (4-stroke)
